Saturn and beyond ...




Saturn 2014

17.05.14  Saturn through a red filter
Altitude 18 - 20 degrees only!
Trutek Type 1  R filter; 21:35:22 - 22:02:35 UTC (27 mins 13 secs video at 10fps)
C14 with x2.5 power mate; ASH atmospheric dispersion corrector;  PGR Flea 3 CCD








Saturn 2013 apparition



17.02.13 Colours distorted by very poor B image
First crude use of ASH atmospheric dispersion corrector.
C14 with x2.5 power mate @ f/27;   PGR Flea 3 CCD; seeing 4/10
Trutek type 1 R, G and B filters (G and B with Baader UV/IR blocker)
R = 05:12:12 UTC; G = 05:26:07 UTC; B = 05:20:20 UTC
RGB with separate R and G beneath






17.02.13  05:50:23 UTC  R filter






07.06.13  21:24 UTC
C14 with x2.5 power mate @ f/27;   PGR Flea 3 CCD
L with Baader UV/IR blocker; ASH atmospheric dispersion corrector









06.06.13  21:56 UTC
C14 with x2.5 power mate @ f/27;   PGR Flea 3 CCD
Trutek type 1 R filter with Baader UV/IR blocker
ASH atmospheric dispersion corrector

















05.06.13  21:38 UTC
Differently processed versions
ASH atmospheric dispersion corrector
C14 with x2.5 power mate @ f/27;   PGR Flea 3 CCD
Trutek type 1 R filterwith Baader UV/IR blocker





02.06.13  22:24 UTC
ASH atmospheric dispersion corrector helping to reveal the Encke Division despite the low altitude!
C14 with x2.5 power mate @ f/27;   PGR Flea 3 CCD
Trutek type 1 R filterwith Baader UV/IR blocker
Drizzled x1.5 then reduced






Non-drizzled versions of the above showing hints of the hexagonal nature of the dark polar region and the ultra narrow Encke division too ...










07.05.13
C14 with x2.5 power mate @ f/27;   PGR Flea 3 CCD; ASH atmospheric dispersion corrector
Trutek type 1 R, G and B filters (G and B with Baader UV/IR blocker), Astronomik IR > 742 nm filter
I = 00:20 UTC; R = 00:29 UTC; G = 00:13 UTC; B = 00:06 UTC
I(95%)RGB





07.05.13  00:29 UTC
C14 with x2.5 power mate @ f/27;   PGR Flea 3 CCD
Trutek type 1 R filter; ASH atmospheric dispersion corrector








07.05.13  00:20 UTC
C14 with x2.5 power mate @ f/27;   PGR Flea 3 CCD
Astronomik IR > 742 nm filter; ASH atmospheric dispersion corrector






07.05.13  00:00 UTC
C14 with x2.5 power mate @ f/27;   PGR Flea 3 CCD
Trutek type 1 R filter; ASH atmospheric dispersion corrector





06.05.13  23:56 UTC
C14 with x2.5 power mate @ f/27;   PGR Flea 3 CCD
Trutek type 1 R filter; ASH atmospheric dispersion corrector






06.05.13  22:40 UTC
Some evidence of dark and light areas in zone above polar region
C14 with x2.5 power mate @ f/27;   PGR Flea 3 CCD
Trutek type 1 R filter; ASH atmospheric dispersion corrector








Saturn 2011




22.4.11
Saturn with 'dragon storm' in NTrZ
C14 @ F27.5, SKYnyx 2-0M CCD
Seeing 5-6/10; good transparency
Trutek R,B filters  Baader UV/IR rejection filter
R[g]B; R = 22:28 UTC,  B = 22:34 UTC









22.4.11
Saturn with 'dragon storm' in NTrZ
C14 @ F27.5, SKYnyx 2-0M CCD
Seeing 5-6/10; good transparency
Trutek R filter  Baader UV/IR rejection filter
R = 22:53 UTC











22.4.11
Saturn with 'dragon storm' in NTrZ
C14 @ F27.5, SKYnyx 2-0M CCD
Seeing 5-6/10; good transparency
Trutek R filter  Baader UV/IR rejection filter
R = 23:44 UTC









25.3.11
Saturn with bright 'storm'
C14 @ F33, Es Reid's spherochromatic correcting lens
SKYnyx 2-0M CCD; seeing 4/10 - 5/10
Trutek R,G,B filters  Baader UV/IR rejection filter
RGB; R = 01:01 UTC, G = 01:09 UTC. B = 01:05 UTC
Separate R, G, B shown below.




Saturn 2009-10










STropZ oval seen again in the above images.









STropZ oval discovered by Tomio Akutsu on 6 Mar seen here at
system III long. 18 +/-2 deg.









STropZ oval discovered by Tomio Akutsu on 6 Mar seen here at system III
long. 16.1 +/- 0.6 deg. This represents a steady positive drift from its
discovery position of System III long. 4 deg. and lat. -41 deg.
















21.2.10
Dione shadow transit faintly visible above ring plane.
Apparent angular diameter = 19.2"(equator);  altitude = 35deg.
 R = 00:44 UT; G = 01:04 UT; B = 00:53 UT.
 C14 @ F38; SKYnyx 2-0M CCD; Trutek R,G,B filters,
 Baader UV/IR rejection filter










Saturn 2008-9








13.4.09

R(80%)RGB. Seeing 5-6/10.
C14 @ F27; SKYnyx 2-0M; Trutek RGB; Baader UV/IR rejection.









20.3.09

R(80%)RGB (R=23:55, G=24:03, B=23:42)  Seeing 5- 6/10.
C14 @ F27; SKYnyx 2-0M; Trutek RGB; Baader UV/IR rejection.


























20.3.09

RGB (R=23:55, G=24:03, B=23:42)  Seeing 5- 6/10.
C14 @ F27; SKYnyx 2-0M; Trutek RGB; Baader UV/IR rejection.


















1.3.09

R(80%)RGB (R=00:45, G=00:18, B=01:08)  Seeing 6-7/10.
C14 @ F27; SKYnyx 2-0M; Trutek RGB; Baader UV/IR rejection.








Shadow transit of Saturn's moon, Rhea (just 0.24" in angular diameter) ...









22.4.09

RRGB (R=21:35-21:42;G=21:46-21:52;B=21:53-21:56). Seeing 4-5/10.
C14 @ F27; SKYnyx 2-0M; Trutek RGB; Baader UV/IR rejection.











Dione in Transit ... just visible!




Upper:
It is just possible to make out the tiny dark shadow on Saturn's moon, Dione
projected onto the cloud tops in the northern hemisphere, immediately below
the dark green/grey belt, slightly left of centre. Its apparent angular diameter
was only 0.16". A white storm is in the southern hemisphere on a similar longitude
may just be seen as a low contrast feature. The rings are inclined at just 0.9 degrees.
Titan is seen to the right (west) of Saturn.
7.12.08   05:54 UT  Seeing: moderate  Transparency: quite good.
C14 @ F27; SKYnyx 2-0M CCD; Trutek R,G,B filters and Baader UV/IR rejection filter.


Lower:
The shadow of Dione is now approaching the right (west) limb. There now appears
to be two very low contrast white storms in the southern hemisphere. Titan is seen
to have moved since the previous image.
7.12.08   07:10 UT  Seeing: moderate  Transparency: quite good.
C14 @ F27; SKYnyx 2-0M CCD; Trutek R,G,B filters and Baader UV/IR rejection filter..





Saturn 2007-8


A greenish spot in STrZ on Saturn ...







23.4.08

RGB (R 22:20, G 22:13, B 22:06); mediocre seeing and transparency.
C14 @ F27; SKYnyx 2-0M; Trutek RGB; Baader UV/IR rejection.




Spot transit time 22:04 UTC +/- 3 mins.



Saturn in very good seeing...





10.2.08

RGB (R  23:19, G  23:28, B  23:38)
C14 @ F27; SKYnyx 2-0M; Trutek RGB; Baader UV/IR rejection.











Separate Channels:-


R


G

B




Alternative versions ...

The version above shows a hint of the Encke Division
towards the extreme right edge of the rings.





16.11.07  05:42 UT




Occultation of Saturn by the Moon




The image was obtained a few minutes after Saturn had emerged from occultation by 39% phase thick crescent moon.
22.5.07   30cm Meade LX200 SCT @ F25, Lu075M CCD.


4.4.07

30cm Meade LX200 SCT @ F25, Baader UV/IR blocker filter and Trutek L,R,G,B filters.



Saturn pre-2007

              22.1.06

30cm Meade LX200 @ F25; Lu075M CCD



      3.4.05

Stack of more than 1,000 .avi video frames for each of the R,
G and B filters. ATK-1HS CCD attached via a x2.5 power mate
to my 30cm Meade LX200 SCT.




1.3.04

Stack of 120 images taken with SXV-H9 CCD and TeleVue 2.5x PowerMate
on my 30cm Meade LX200. The colour information came from images taken
through True Technology Ltd R, G and B filters.


Saturn and satellites about to be occulted by the Moon
on 16th April 2002 ...






Uranus


Uranus and its Moons

Quite a challenge! Here the brightness of Uranus relative to its moons has been substantially reduced
to avoid saturation of the image.


Left:

21.9.08   00:56 UT (central time for satellite images)
From top to bottom: Umbriel, Ariel, Uranus, Oberon, Titania.
Uranus apparent angular diameter = 3.66".
C14 @ F28: satellite data from SXV-H9 CCD stack of 192 x 2s; Trutek L filter and Baader UV/IR rejection filter binned 4x4
Uranus data from SKYnyx 2-0M CCD with Baader UV/IR rejection filter and Trutek R, G, B filters.


Right:

31.8.08   01:09 UT (central time for satellite images)
From top to bottom: Titania, Umbriel, Ariel, Uranus.
Uranus apparent angular diameter = 3.66". Seeing Pickering 7+ but poor transparency.
C14 @ F44: SXV-H9 CCD Baader UV/IR rejection filter,  Trutek R, G, B filters: R = 14 x 2s, G = 45 x 2s; B = 16 x 2s.


The green with a hint of blue colouration of Uranus
is due to the presence of methane in its atmosphere.




14th 16th
Above: Not a gas giant, but ... Pluto reveals itself by its motion over a two day
period in July 1999
